Off-grid inverterSPI-8K-UP SPI-10K-UPPhase separation110/120V 8kw 10kwHousehold hybrid solar inverter

Name: Offgrid inverterSPI8KUP SPI10KUPPhase separation110120V 8kw 10kwHousehold hybrid solar inverter
Brand: HUALIAN
Price: 1 USD

Buy cheap Off-grid inverterSPI-8K-UP SPI-10K-UPPhase separation110/120V 8kw 10kwHousehold hybrid solar inverter product

Certification : RoHS, ISO

Place of Origin : China

Brand Name : HUALIAN

Model Number : HUALIAN

Contact Now

重要属性

输出类型

分相

逆变器效率

97.6%

原产地

shenzhen, China

型号

SPI-8K-UP SPI-10K-UP

品牌

hualian

输入电压

125 ~ 425Vdc

输出电压

120V/240V

输出电流

63A

输出频率

50Hz/60Hz

尺寸

620*445 * 130mm

类型

直流/交流变频器

重量

27kg

类型

纯正弦波逆变器

产品名称

Srne混合逆变器

应用程序

家用太阳能发电系统:

逆变器类型

离网电源逆变器

电池类型

铅酸锂

关键词

太阳能电源逆变器

保护

IP20

噪声 (dB)

60dB

通信

RS485/CAN/USB/干触点

冷却

内部风扇

包装和发货信息

包装细节

聚木托盘 + 标准碳盒

销售单位

HUALIAN

单个包装尺寸

72X55X23 cm

单个产品毛重

37.000 KG

产品描述

离网逆变器SPI-8K-UP SPI-10K-UP分相110/120V 8kw 10kw家用混合太阳能逆变器

规格

模型	SPI-10K-UP	SPI-8K-UP
逆变器输出
额定输出功率	10,000瓦	8,000W
最大峰值功率	20,000瓦	16,000瓦
额定输出电压	120Vac,单相/240Vac,分相/三相,并联
电机的负载能力	6HP	5马力
额定交流频率	50/60赫兹
波形	纯正弦波
切换时间	10毫秒 (典型值)
并联容量	1 ~ 6台
输出模式	离网 (默认)/混合动力
电池
电池类型	锂离子/铅酸/用户定义
额定电池电压	48Vdc
电池电压范围	40 ~ 60伏直流电
最大MPPT充电电流	200A	180A
最大电源/发电机充电电流	120A	100A
最大混合充电电流	200A	180A
光伏输入
MPPT跟踪器的数量	2
最大光伏阵列功率	5,500W + 5,500W
最大输入电流	22A + 22A
最大开路电压	500伏直流电 + 500伏直流电
MPPT电压范围	125 ~ 425伏直流电
公用事业/发电机输入
输入电压范围	90 ~ 140伏交流电
频率范围	50/60Hz
旁路过载电流	63A
一般
尺寸	620445 130毫米
重量	27千克
防护度	IP20,仅限室内
工作温度范围	-10 ~ 55 ℃,> 45 ℃ 降额
噪声	<60dB
冷却方法	内部风扇
保修	18个月
沟通
嵌入式接口	RS485 / CAN / USB/干式触点
外部模块 (可选)	无线网络/GPRS

Off-grid inverterSPI-8K-UP SPI-10K-UPPhase separation110/120V 8kw 10kwHousehold hybrid solar inverter

Shenzhen Hualian Weiyip Technology Co., Ltd. was founded in 2011, with a production workshop of 5,000 square meters and 600 employees. In 2023, the company's sales will reach 300 million yuan. The company's inverter business is cooperating with 16 countries.We are committed to the ultimate pursuit of product quality and efficiency, providing highly reliable solutions for customers around the world. If you have any questions please visit our online showroom or contact us for more details.
